2000L Low Pressure Solar Collector Centralized Solar Water Heating System

Working Principle
1. Firstly, the storage tank shall be filled with cold water, the collector loop shall be pumped with water
2. The water in collector loop then will be heated with solar radiation to vacuum tubes
3. When temperature discrepancy sensed between solar collector and storage tank reaches set value in controller, the controller shall start the circulation pump automatically
4. The circulation pump makes water circulate in the loop
5. Hot water would be pumped into storage tank and the loop again be pumped with cold water from the bottom of storage tank
6. In case the temperature in storage tank does not reach set value you want, then the auxiliary electrical heater would start to assist heating
7. When temperature discrepancy sensed between solar collector and storage tank is below the set value in controller, the circulation pump shall stop automatically
8. If the water temperature has not reached the expected value set in the controller, then the auxiliary heating device would start to assist solar water heating
9. Eventually the water will get heated enough as expected ready for use

Advantage
1) Strong adaptability
2) Wide application occasions
3) High degree of automation
4) Economical and practical
5) Environmental conservation and energy
6) In large-scale projects, auxiliary heating system, computerized controller and pipe cycling system
7) According to the required configuration, it can be divided into two types. One is vertical and the other is horizontal
8) with large heat collecting capacity

Applications
1) Hotels, resorts, hospitals and hostels
2) Process industry, boiler feed, laundry and canteens
3) Agricultural sector, hatcheries and dairies
4) Process industry, Boiler feed, Laundry and canteens
5) Agricultural sector, hatcheries, and dairies
6) Swimming pool heating
7) In-process heating
8) Health clubs (Steam / Sauna)

Specifications

Warranty:

6 years international responsibility for U pipe solar collector and 15 years for vacuum tubes due to original quality problems.

Payment term:
1. T/T 30% Deposit in advance and balance should be paid after receiving the B/L copy.
2. L/C at sight (if your quantity reaches 5*40’ HQ container)
3. Sample order or LCL: we accept western union and one touch business.

Packaging & Delivery
Packaging Details:
Export carton for full container.
Delivery Detail:
7 days after receiving the deposit.



PDF Catalogue of Non Pressure Solar Collector.

PT-NC Non Pressure Solar Collector.pdf

JIAXING PASSION NEW ENERGY TECHNOLOGY CO., LTD. is a manufacturer of Solar Water Heater since 1996.

As an experienced company, we can provide the perfect solution for Solar Thermal System.

Our products include solar water heater, solar collector and accessories.
We have advanced technology and equipment, specialized in producing the following solar thermal products:
A. Thermal Solar Water Heater

B. Flat Plate Solar Water Heater

C. Heat Pipe Solar Water Heater

D. Vaccum Tube Solar Water Heater

E. Split Solar Water Heater

F. Pre Heated Solar Water Heater

G. Flat Plate Solar Collector

H. Heat Pipe Solar Collector

I. U Pipe Solar Collector

J. Vacuum Tube Solar Collector

The solar water heater applies to family, underfloor heating, factory, hotel, swimming pool etc.
Survive on quality and seek development with prestige.
Welcome to visit our factory for friendship and business.
